Is this practical?
I have a 35 ft boat with a very old 671 diesel with a 1.5 to 1 reduction gear. I am installing a 6 HP Petter diesel aux which will probably give me about 3 KW of electric power when coupled to a generator. I have a really nice 5 HP 24 VDC PM continuous duty motor and a DC motor controller that can handle 375 AMPS. When my main engine gearbox is in neutral, it is fairly easy to turn the shaft, not a lot of friction. If I put the boat in gear and crank my starter motor with the fuel shut off to the main engine, I move some water with the prop, not a lot, but it is turning slow and doesnt seem to bog down the starter much motre than if the gearbox were in neutral. I'd like to just put a flat (no protruding center coupling) chain sprocket between my propshaft coupling faces and have the coupling bolts go through holes in the sprocket to affix the sprocket firmly between the flanges when they are recoupled. That should only move my prop back an distance equivalent to the thickness of the sprocket. I propose to have the DC motor set up to drive the propshaft through roller chain which would only be connected in case of a main engine failure. I'll figure out the right ratios between the motor sprocket and propshaft sprocket to avoid overloading the DC motor. If my main engine is diabled, do you think this set up would get me home using the Petter driven gen as a power source? I'll probably use a 110 AC gen and convert it to 24 DC with a power supply. Even one or two knots might help in a jam. Your thoughts? Any good web info on this type of setup? |
